Monthly Safety Scenario (MSS)
The Monthly Safety Scenario (MSS) is a Loss Prevention initiative to assist members in their efforts to comply with international safety regulations and to follow best practices.
The Club is publishing, every month, a new Monthly Safety Scenario (MSS) to assist owners in their efforts to comply with the above regulations. Alternative scenarios will be uploaded in SCOL. It is easy to download the MSS and enter the written conclusions from the meeting and send feedback to the shore-based organisation.
MSS Case May: Engine room fire caused by crack in fuel oil pipe
During a routine ballast passage in open waters, a 12 year old product tanker was operating under normal conditions with both main engines running. At the time of the incident, there were no abnormal machinery readings, alarms, or operational restrictions. In the early afternoon, the engine room fire detection system activated simultaneously on the bridge and in the engine control room. The alarm indicated a fire on the starboard side of the engine room, in way of the starboard main engine. Engine room personnel responded immediately and confirmed the presence of fire and dense smoke in the vicinity of the engine room stairway adjacent to the main engine.
The bridge team stopped the main engines without delay, and emergency response procedures were initiated in accordance with the vessel’s Safety Management System. Fire parties were mustered, boundary cooling was established, and local firefighting actions were taken using portable firefighting equipment. Access to the affected area was restricted to limit air supply and slow the development of the fire.
Despite the prompt response, the fire escalated rapidly and could not be controlled locally. Given the location of the fire near the main engine, fuel oil pipework, and hot exhaust components, the risk of further escalation was assessed as significant. The Master therefore made the decision to release the fixed CO firefighting system protecting the engine room. The CO system was released within a short time of the initial alarm and successfully extinguished the fire. The engine room was sealed, and re entry was carried out only after conditions were confirmed safe.
No injuries were reported, and there was no reignition. Following extinguishment, the crew concentrated on restoring essential shipboard functions. Electrical power was progressively re established, and systems required for navigation and vessel control were brought back into operation. Through sustained effort under demanding conditions, the crew succeeded in restoring limited propulsion capability within a short period, allowing the vessel to proceed under its own power and avoid the need for towage. The fire was caused by a crack in a pressurised fuel oil pipe located in the vicinity of the starboard main engine. The crack allowed fuel oil to escape under pressure as a fine spray, which subsequently came into contact with a hot surface and ignited, resulting in a rapidly developing engine room fire. The failure was the result of fatigue cracking caused
by long term vibration and cyclic stress, a mechanism particularly relevant on vessels that have been in service for more than a decade.
Throughout the incident, the crew demonstrated effective communication, disciplined emergency response, and strong technical competence under pressure.
Questions
When discussing this case please consider that
the actions taken at the time made sense for all
involved. Do not only judge but also ask why you
think these actions were taken and could this
happen on your vessel?
- Does our SMS address these risks?
- What sections of our SMS would have been
breached if any? - Do we inspect the insulation in the engine room?
- How do we ensure that insulation is adequate in
the engine room? - When maintenance has been completed do
we inspect that the insulation is in place
and not contaminated? - What signs of vibration or fatigue damage on fuel
pipes might we overlook or underestimate?
- Do we have thermographic measurement cameras to ensure insulation is put back in order and to be able to verify that the machinery surfaces are below 220 deg C?
- How does vessel age influence our approach to
machinery inspections, particularly for fuel systems
exposed to long term vibration and cyclic stress? - What lessons can be learned from this incident to
reinforce safety culture onboard? - What additional training or practical drills could help
the crew be better prepared for real-life scenarios? - What support do we need from management
(additional training, updated procedures, more
resources) to strengthen our procedures? - What immediate, actionable steps can we take
from today’s discussion?
The Swedish
Downloads
MSS Case May: Engine room fire caused by crack in fuel oil pipe
MSS Case May: Engine room fire caused by crack in fuel oil pipe
Under the ISM requirement, owners are obliged to carry out monthly safety meetings or safety committee meetings onboard their vessels. This obligation stems from Chapter 5 of the ISM Code: “Master’s responsibility and authority” and furthermore from “5.1.2, motivating the crew in the observation of that policy”.
The obligation can also be derived from the Code of “Safe Working Practices for Merchant Seamen”, where it is stated that the safety committee should meet regularly: “3.13.2, The frequency of meetings will be determined by circumstances but as a general guideline, the committee should meet about every 4-6 weeks”.
For more Loss Prevention information, please contact:
Joakim Enström, Loss Prevention Manager
E-mail: joakim.enstrom@swedishclub.com
